Residential Combustion Analyzer Kit w/ Printer/Case
C161KIT
The C161 Residential Combustion Analyzer equips HVAC/R professionals to install and maintain furnaces and boilers to optimize efficiency and reduce fuel costs.
The C161 combustion analyzer is eligible for UEi Service+, which offers transparent recertification pricing, warranty extensions up to 6 years from the date of purchase, 24-hour turnaround, and free UPS Ground shipping to and from our ISO certified Indianapolis service center.
C161 has two levels of sensor protection; a NOx filtered CO sensor and Low Flow Detection. It also has sensor technology that reduces the cost of ownership, a Heat Exchanger test to check the exchanger integrity, and differential temperature. The C161 comes with high altitude compensation to maintain accurate readings at any altitude, auto-purge shut off, and 8 Pre-programmed fuels including Natural Gas and Propane.
The C161 has a 6-Line display to view readings on one screen, which is a favorite among technicians. The DMM Style dial makes it easy to select the test needed. It also features a water trap to protect the sensor with a check light to remind to look for condensate built-up, a magnetic boot for hands-free operations, and an IR printer port to print to the IR thermal printer, making it easy to document test results for later analysis.


Up to 6 Year warranty with annual recertification Yes
Eligible for UEi Service+ Yes
2 Types of sensor protection Yes
NOx Filtered Yes
Low Flow Detection Yes
Backlight Yes
Temp differential Yes
Wireless output Yes
Protective boot or overmolding Yes
Start time 30 second
High altitude compensation Yes
Memory Positions 30
Magnetic mount Yes
Warranty 1-Year limited
Recording/Data Logging Yes
K-type input Yes
Digital Yes
Automatic fresh air purge Yes
On board plain paper printer Yes
Number of display parameters 6 line
IR printer link Yes
Protective Water Trap Yes

CO 2000ppm
CO2 20%
O2 21%
Flue temperature 32˚ to 1112˚F
Inlet temperature 32˚ to 1112˚F
Heat exchanger test Yes
Differential Temperature Yes
K-type Temperature Range -40˚ to 950˚F (-40˚ to 510˚C)

CE Conformity Yes
RoHS Yes
REACH Compliant Yes
AHRI 1260 Standard AHRI 1246 Standard

Quick Start Guide Yes
Pouch/Cases AC509
Infrared printer IRP-2
Printer paper roll 16646
USB cable Yes
Charger AACA5
Water trap Yes
